Head Office – PRECI-TECH ENGINEERING SERVICES
Responsibilities – For Marketing, Sales, Purchase, Development of sub-contractors, Commercial-Costing, Import, Export and Logistics.
Manufacturing Unit – I
Responsibilities – CNC & VMC Turning, VMC process design & manufacturing, Production Planning & Scheduling, Sub-contracting of operations like Heat Treatment, Surface Treatment, Grinding, Honing, Inspection, Packing and Delivery.
Manufacturing Unit – II
Responsibilities – VMC & CNC Turning, Fixturing & Tool Design, Process Mapping, Manufacturing, Production Planning and Scheduling, Subcontracting, Support to Marketing & Sales, Customer coordination, Management of sub-contracting operations, Quality, Production planning & control.
15CNC TURNING CENTER (Lathe)1Ace Designers Ltd SJE 08 LMMax turning dia 300 mm, Turning Length 500 mm
LIST OF MACHINERIES & QUALITY EQUIPMENTS |
|||||
| Sr No | Machine Name | QTY | MAKE | WORKING DIMESNIONS | PHOTO OF MACHINE |
|---|---|---|---|---|---|
| 1 | CNC TURNING CENTER (Lathe) | 2 | Ace Designers Ltd | Max turning dia 250 mmDia. 165 mm ChuckMax turning length 400 mm |  |
| 2 | CNC TURNING CENTER (Lathe) | 1 | Pride Ultra Lynx | Max turning dia 250 mmDia. 200 mm ChuckMax turning length 400 mm |  |
| 3 | CNC TURNING CENTER (Lathe) | 1 | Pride Jaguar | Max turning dia 300 mmDia. 200 mm ChuckMax turning length 510 mm |  |
| 4 | CNC TURNING CENTER (Lathe) | 1 | Ace Designers Ltd | Spindle A2-6, 53mm Bar CapacityDia. 200 mm ChuckMax Turning Dia 320 mmMax Turning Length 500 mm |  |
| 5 | Vertical Machining Center | 1 | Jyoti Make PX 20 | Table size 660X440BT 40 spindle , Max RPM 8000X Axis Travel 510Y Axis Travel 510Z Axis Travel 510 |  |
| 6 | Vertical Machining Center | 2 | Cosmos make CVM640 | Table size 8000X450BT 40 spindle,Max RPM 8000X Axis Travel 650Y Axis Travel 450Z Axis Travel 510 |  |
| 7 | Vertical Machining Center | 2 | AMS Make SuperWinner | Table size 800X450BT 40 spindle,Max RPM 6000X Axis Travel 500Y Axis Travel 400Z Axis Travel 500 |  |
| 8 | Vertical Machining Center | 1 | AMS Make MCV-400 | Table size 900X450BT 40 spindle,Max RPM 6000X Axis Travel 600Y Axis Travel 450Z Axis Travel 500 |  |
| 9 | Vertical Machining Center | 1 | AMS Make Super Winner | Table size 1000X510BT 40 spindle,Max RPM 6000X Axis Travel 800Y Axis Travel 510Z Axis Travel 500 |  |
| 10 | Measuring Instruments : | 1 | Mitutoyo | 2D Height gauge 600 mm Length |  |
| 11 | Surface Finish Tester SJ-200 | 1 | Mitutoyo | Digital |  |
| 12 | CNC Tilting Table | 8 | UCAM | Dia 200 Tilting table For universal | |
| Fourth Axis | PRAGATI | angular positioning | |||
 |
|||||
| 13 | Universal Tapping Machine | 1 | Unity |  |
|
| 14 | CAD/CAM Software : for Multi axis Turning and Multi axis VMC for production part machining including multiaxis machining with turning milling capabilities. 2 separate seats for turning and milling with network licences. | 1 | EDGECAM – VERO | Edgecam Advanced MillingEdgecam Advanced TurningEdgecam Solid Machinist MaxAdvanced 5 Axis Simultaneous MillingEdgecam Advanced Designer |  |
| 15 | CNC TURNING CENTER (Lathe) | 1 | Ace Designers Ltd SJE 08 LM | Max turning dia 300 mm Turning Length 500 mm |  |
| 16 | Vertical Machining Center | 1 | AMS Make 430 V | Table size 650x300X Axis Travel 400Y Axis Travel 300Z Axis Travel 400 |  |
| 17 | Coordinate Measuring | 1 | Accurate Make | X Axis Travel 1000 |  |
| Machine – CMM | Model-Spectra 8106 | Y Axis Travel 800 | |||
| Z Axis Travel 500 | |||||
